Binokularni mikroskop BM-700

Binokularni mikroskop BM-700

Our new advanced biological Microscope for educational, teaching, life science and clinical applications. The Anti-Fungus treatment protects the optical system, objectives and eyepieces in high-humidity environments.
The new designed F=200 mm Infinite Plan achromatic objectives provide a fully corrected image for clear visual and digital results.


Code: Description: Head:
BOE 7000.570 BM-700/I/PL Binocular
BOE 7000.580 BM-700/T/I/PL Trinocular
Objectives for BM-700
Code: Description:
BOE 7000.552 BOECO Infinity Plan Achromatic AF Obj. 4X
BOE 7000.553 BOECO Infinity Plan Achromatic AF Obj. 10X
BOE 7000.559 BOECO Infinity Plan Achromatic AF Obj. 20X
BOE 7000.554 BOECO Infinity Plan Achromatic AF Obj. 40X (S)
BOE 7000.555 BOECO Infinity Plan Achromatic AF Obj. 100X (S) (Oil)


Optical Head: Seidentopf Binocular Head,
with high quality infinitive optical system
Nosepiece: Backward quadruple revolving nosepiece
Eyepiece: Pair Eyepiece WF 10X /20 mm, diopter adjustable, with anti fungus treatment, Interpupillary Distance 47-75 mm
Objectives: BOECO Anti Fungus Infinite Plan Achromat Objectives 4x, 10x, 40x (S), 100x (S) (Oil)
Stage: Double layer mechanical specimen stage. 216 x 150 mm Travel area 78 x 54 mm, Right hand stage handle
Focusing: Low position, coaxial coarse and calibrated fine focus control, with graduation reading 2 microns per division. Total focusing range 20 mm, Safety autofocus stop unit.
Condenser: Sliding-in centerable Bright field condenser, n.A. 1,25, Integrated Iris diaphragm and filter tray.
Illumination: S LED lamp, light intensity adjustable.
Body /power: Sturdy body with supportive rubber and inbuilt power supply 100 – 240V
Supplied with: Dust cover, green filter, immersion oil and instruction manual
Dimension: 230 x 376 x 406 mm
Weight: Netweight 8 kgs, Grossweight 9 kg
Packing: styrofoam shelve in a cardboard box


Code: Description:
BOE 7000.303 WF eyepiece 10x/20 with Micrometer
BOE 7000.302 WF eyepiece 10x/20 with Pointer
BOE 7000.307 WF eyepiece 10x/22
BOE 7000.304 Eyepiece 15x/16
BOE 7000.702 Collector, Field Iris Diaphragm and Auxiliary Lens for Koehler Illumination
BOE 7000.305 Dark Field Condenser (Dry) NA 0,9
BOE 7000.306 Dark Field Condenser (Oil) NA 1,36-1,25
BOE 7000.325 Polarization attachment
BOE 7000.903 Phase Contrast kit, dial type. Consisting of Phase Contrast Infinity Plan-achromatic Objectives 10X, 40X(S), 100X(S,Oil), Turret Annular Phase Contrast Condenser, Green Filter
BOE 7000.906 Epi-Fluoresence attachment, power supply, mercury lamp, blue and green filter
BOE 7000.907 Epi-Fluoresence attachment FL-LED, with B excitation filter (465-475 nm blue) and LED lamp
