Microplate photometer HIPPO MPP-96

Microplate ELISA Photometer HiPo is a compact table top device for measuring the results of ELISA and micro- biological studies using 96-well microplates. Instrument is controlled and outputs data via computer.
HiPo is supplied with analysis software QuantAssay.QuantAssay features:

Analysing any ELISA assay can be included via robust Assay Editor
Avidity assays
Multiplex assays with up to different 7 assays on one plate
Qualitative assay with up to 8 controls
Quantitative assay with up to 20 standards
Powerful BestFit function for fitting the best calibration curve
Results saving, loading, exporting

Kategorija: Spektrofotometri

Opis
Recenzije (0)

Code:	Description:
BOE 8077000	HiPo MPP-96 Microplate Photometer, 100-240 V, 50/60 HZ

Specification:
Detection mode:	Absorbance
Light source:	LED, self-calibrating
Photodetector:	8 silicon photodiodes
Plate type:	96-well microplates (including strip-well microplates)
Reading Speed:	5-8 sec. per wavelength
Measurement modes:	Endpoint, kinetic and multi-label measurements
Measurement channels:	8
Reference channel:	1
Measurement range:	0 – 4.3 OD
Resolution:	0.0001 OD
Wavelength range:	400 – 750 nm
Wavelength selection:	Standard filters 405, 450, 492 and 620 nm. Up to 8 filters on wheel (up to 4 custom filters can be fitted on demand)
Shaking:	4 amplitudes, 4 speeds
Software:	QuantAssay
PC system requirements:	Intel/AMD Processor, 1 GB RAM, Windows Vista/7/8, 2.0 USB
Overall dimensions:	(W × D × H) 140 x 300 x 130 mm
External power supply:	Input AC 100–240 V 50/60 Hz, Output DC 12 V
Weight:
Accuracy at 450 / 492 nm
0.000 – 2.000 OD	≤ (0.5 % ± 0.010 OD) typical
2.000 – 3.000 OD	≤ (1 % ± 0.010 OD) typical
Precision / Reproducibility at 450 / 492 nm
0.000 – 2.000 OD	≤ (0.5 % ± 0.005 OD)
2.000 – 3.000 OD	≤ (1.0 % ± 0.005 OD)
Linearty
0.000 – 2.000 OD	≤1.0 %
2.000 – 3.000 OD	≤1.5 %
