| Specification: |
|
| Optical Head: |
Binocular or Monocular Head, 30° inclined, 360° rotatable, |
| Nosepiece: |
Backward Quadruple revolving nosepiece |
| Eyepiece: |
Widefield Eyepiece WF 10X /18 mm |
| Objectives: |
Achromatic DIN Objectives 4x/0.10, 10x/0.25, 40x/0.65 (S), 100x/1.25, Oil, (S) |
| Stage: |
Double Layers mechanical stage 132 x 142 mm Travel aerea 75 x 40 mm, |
| Focusing: |
Coaxial Coarse & Fine Adjustment System Range 24 mm, Fine Division 0,004 mm |
| Condenser: |
Abbe Condenser, n.A. 1,2, with iris diaphragm and filter |
| Illumination: |
3W LED. light intensity adjustable |
| Supplied with: |
Dust cover, Blue+green filter, spare fuses, Immersion oil |
| Dimension: |
170 x 310 x 355 mm, netweight 5 kg |
| Packing: |
Styrofoam shelve in a cardboard box |
